CR One Thousand Twenty Five
Model：CR One Thousand Twenty Five
brand：Chen Mu
Voltage(V)：3V
capacity(mAh)：
size(mm)：10.0*2.5 mm
Texture of material：Lithium manganese dioxide
Adaptable products：electron products
working temperature range：-20℃～60℃
Product introduction
RATINGS
TABLE Ⅰ：
ITEM | UNIT | SPECIFICATIONS | CONDITIONS | |
Nominal voltage | V | 3.0 | ||
Nominal capacity | mAh | 30 | Standard discharge with load 15kΩ | |
Instantaneous short–circuit current | mA | ≥80 | Time≤0.5 second | |
Off-load voltage | V | ≥3.2 | ||
Operating temperature | ℃ | -20~60 | ||
Standard weight | g | 0.6 | Unit cell | |
Service output | Initial | Standard | 150 h | Continuous discharge with load 15kΩ, till 2.0v end-voltage |
After 12 months storage | Standard | 145 h | ||
TABLE Ⅱ：
ITEM | CONDITIONS | CHARACTERISTICS | |
Thermal durability | Kept for 20 days at 60℃±3℃, then continuously discharge with 15kΩ load till 2.0v end-voltage | Standard | 140 h |
Self-discharge rate | Stored for 12 months at normal temperature and humidity | ≤5% | |
